Fully Automatic High Purity 99.9995% Hydrogen Dryer Equipment for Chemical

उत्पाद विवरण:

उत्पत्ति के प्लेस:	Suzhou,China
ब्रांड नाम:	SINCE-GAS
प्रमाणन:	CE,ABS,CCS,BV,DNV,ASME,GOST,
मॉडल संख्या:	PH-A-H

भुगतान & नौवहन नियमों:

न्यूनतम आदेश मात्रा:	1 set
मूल्य:	Negotiate
पैकेजिंग विवरण:	Normal exported wooden case
प्रसव के समय:	2 months after received down payment
भुगतान शर्तें:	L/C, T/T, Western Union, MoneyGram
आपूर्ति की क्षमता:	1000 sets/year

संपर्क करें

विस्तृत उत्पाद विवरण

सामग्री:	कार्बन स्टील / स्टेनलेस स्टील	क्षमता:	50-5000Nm3/एच
ओसांक:	-70 ℃	राज्य:	एकदम नया
प्रचालन की विधि:	पूरी तरह से परमाणु	आवेदन:	रासायनिक के लिए हाइड्रोजन जलशुष्कक ड्रायर
हाई लाइट:	जलशुष्कक एयर ड्रायर , प्रशीतित संपीड़ित एयर ड्रायर , उच्च शुद्धता हाइड्रोजन ड्रायर उपकरण

Fully Automatic High Purity 99.9995% Hydrogen Dryer Equipment for Chemical

Hydrogen dryers

Hydrogen dryer for hydrogen-cooled generators is a dual-absorber unit that continuously removes moisture from recirculated hydrogen, keeping the internal components of the turbine in a completely

dry hydrogen atmosphere. The unit uses regenerative type desiccant and is fully automatic

in operation. It is heat reactivated with embedded electric heaters.

Accomplishes reactivation with a completely closed-circuit system, thereby eliminating any purge loss

or infiltration of atmosphere into the system.

High quality desiccants

High quality, extra activated alumina is respectively filled in each tower ;

Controller Reliable Timed controller Field proven over time, this design and technology maintain precise

control over all switching and purge valve functions.

Opional for PLC controller,PLC Controlling system

executes and monitors all dryer functions;

7 Colorful Touch screen panel displays dryer status.

Pressure Gauges Stainless steel gauges, located on each tower, provide visual indication of
