Name: Pressure Swing Adsorption / PSA Nitrogen Generator For Tungsten Power
Brand: SINCE GAS
SKU: PN-NP-C-80-595
Rating: 4.5 (161 reviews)

होम उत्पाद PSA Nitrogen Generator

Pressure Swing Adsorption / PSA Nitrogen Generator For Tungsten Power

उत्पाद विवरण:

उत्पत्ति के प्लेस:	Suzhou
ब्रांड नाम:	SINCE GAS
प्रमाणन:	CE,,BVC,ABS,CCS,LR,DNV,LR,ASME
मॉडल संख्या:	PN-NP-C-80-595

भुगतान & नौवहन नियमों:

न्यूनतम आदेश मात्रा:	1 set
मूल्य:	negotiate
पैकेजिंग विवरण:	exporting standard packing
प्रसव के समय:	within 2-3 months
भुगतान शर्तें:	L/C, T/T, Western Union, MoneyGram
आपूर्ति की क्षमता:	80 sets per month

संपर्क करें

विस्तृत उत्पाद विवरण

सामग्री:	कार्बन स्टील	प्रमाण पत्र:	सीई, एबीएस, एएसएमई, बीवी
पवित्रता:	99.9995%	आवेदन पत्र:	भागों के साथ टंगस्टन शक्ति
मैदान:	पाउडर और हार्डवेयर	रंग:	धूसर सफेद
डिजाइन कोड:	एएसएमई/सीई/जीबी
हाई लाइट:	सा नाइट्रोजन संयंत्र , पीएसए नाइट्रोजन गैस जनरेटर , टंगस्टन पावर पीएसए एन 2 जेनरेटर

CE/ASME verified nitrogen generator for Tungsten power with parts ,hardware

SINCE GAS Pressure Swing Adsorption (PSA) type Nitrogen Generator provides a cost-effective means for on-site N2 solution. The Nitrogen Generator uses two beds of CMS to separate compressed air into a high-pressure nitrogen product stream and low-pressure oxygen enriched waste stream. Therefore, CMS is very crucial for nitrogen generator , but water, oil, granule need removed before entering into nitrogen generator .

Technical characteristics

More reliable:
* standardized air separation systems based on proven state of the art technologies in history of many years application in fields.
* Simplified engineering design idea with much less moving parts, guarantees maximum reliability and minimal maintenance

More economical:
* More advanced and more economical air separation modules.
* REFLUX composition control system reduces air consumption capacity, saves energy cost.
* Patented Energy Efficiency System (EES) enables our systems to produce product gases based on actual demand.

More convenient:
* Diversification monitoring and control system enables parameters of capacity, purity, and pressure of product gases online display on panel screen, gives running problem alarm, and reminds of maintenance.
* Turn-key solution and pre-commissioned.
* Skid mounted design, easy installation..

Specifications:

No	Model	Capacity(Nm3/h)	Purity	Power(KW)	Overall size(mm)
1 2 3 4	PN-3-39 PN-5-29 PN-5-295 PN-8-295	3 5 5 8	99.9% 99.5% 99% 95%	0.5	180014001500
5 6 7 8	PN-5-49 PN-8-39 PN-12-295 PN-15-29	5 8 12 15	99.99% 99.9% 99.5% 99%	0.5	180014001800
9 10 11 12	PN-10-49 PN-15-39 PN-25-295 PN-30-39	10 15 25 30	99.99% 99.9% 99.5% 99%	0.5	200017002250
13 14 15 16	PN-15-49 PN-22-39 PN-35-295 PN-45-29	15 22 35 45	99.99% 99.9% 99.5% 99%	0.5	210018002200
17 18 19 20	PN-20-49 PN-30-39 PN-50-295 PN-60-29	20 30 50 60	99.99% 99.9% 99.5% 99%	0.5	220018002200
21 22 23 24	PN-30-49 PN-45-39 PN-75-295 PN-88-29	30 45 75 88	99.99% 99.9% 99.5% 99%	0.5	240019002200
25 26 27 28	PN-40-49 PN-60-39 PN-100-295 PN-120-29	40 60 100 120	99.99% 99.9% 99.5% 99%	0.5	250021002500
29 30 31 32	PN-50-49 PN-70-39 PN-120-295 PN-140-29	50 70 120 140	99.99% 99.9% 99.5% 99%	0.5	260022002850
33 34 35 36	PN-60-49 PN-90-39 PN-160-295 PN-190-29	60 90 160 190	99.99% 99.9% 99.5% 99%	0.5	280022002500
37	PN-80-49	80	99.99%	0.5
38 39 40	PN-120-39 PN-200-295 PN-250-29	120 200 250	99.9% 99.5% 99%	0.5	320014002800
41 42 43 44	PN-100-49 PN-140-39 PN-250-295 PN-290-29	100 140 250 290	99.99% 99.9% 99.5% 99%	0.5	350015002800
...	...	...	...	...	...
Note:More news please free to contact Since Gas System Co.,Ltd or send email to us directly

Why SINCE-GAS?

-COST SAVINGS
You can save Nitrogen costs by generating your our nitrogen on-site, produce your own nitrogen , payback only couple of months .
Save on:
Transporation Costs
Bulk Liquid Evaporation Loss
Renting costs
Handling and Purchasing Costs

- Convenient
Produce your own nitrogen for production line , demand, to avoid transporation fault cause stop production line problems.
