CE Certified PSA Nitrogen Generator 95-99.9995% Purity

CE Certified PSA Nitrogen Generator 95-99.9995% Purity

सा नाइट्रोजन संयंत्र

पीएसए नाइट्रोजन गैस जनरेटर

सीई सत्यापित नाइट्रोजन जनरेटर

Place of Origin:

Suzhou

ब्रांड नाम:

SINCE-GAS

प्रमाणन:

CE,ABS,DNV,CCS,LR,BV,ASME,GOST

Model Number:

PN-NP-C

हमसे संपर्क करें
एक उद्धरण का अनुरोध करें
उत्पाद विवरण
Features:
High purity
Material:
Carbon steel or stainless steel
Certificates:
CE,ABS,CCS,BV,DNV,LR,
Pressure:
8-10 bar
Purity:
95%-99.9995%
Dew point:
-40 - 70℃
Adsorbent:
CMS
प्रमुखता देना:

सा नाइट्रोजन संयंत्र

,

पीएसए नाइट्रोजन गैस जनरेटर

,

सीई सत्यापित नाइट्रोजन जनरेटर

भुगतान और शिपिंग की शर्तें
Minimum Order Quantity
1 set
मूल्य
negotiable
Packaging Details
Normal standard exporting packing
Delivery Time
2-3 months
Payment Terms
L/C,T/T,Western Union,MoneyGram
Supply Ability
70 sets per year
उत्पाद वर्णन
CE Verified PN-NP-C High Purity Nitrogen Generator 95%-99.9995%
Product Specifications
Attribute Value
Material Carbon steel or stainless steel
Certificates CE, ABS, CCS, BV, DNV, LR
Pressure 8-10 bar
Purity 95%-99.9995%
Dew point -40 - 70℃
Adsorbent CMS
Product Description

The CE verified PN-NP-C High Purity Nitrogen Generator delivers exceptional performance with purity levels ranging from 95% to 99.9995%.

  • Purity: 95%-99.9995%
  • Energy-saving design
  • 20+ years working life
  • Fully automatic operation
Item Specification
Nitrogen High purity 99.9995%
Energy Excellent energy-saving
Working life >20 years
Operating method Fully automatic
Certificates CE, TUV, CCS approved

Using PSA technology, the nitrogen generator isolates nitrogen molecules from other molecules in compressed air (water, oxygen, CO2, etc). The carbon molecular sieve (CMS) adsorbent retains all other molecules while allowing nitrogen to pass through. The system features two towers - one working while the other regenerates by releasing CO2 and oxygen, with a switching cycle of approximately 58 seconds.

Technical Features
  • Principle: Pressure swing adsorption (PSA) technology using carbon molecular sieve (CMS)
  • N2 flow: 5-5000 Nm3/h
  • O2 purity: 1% to 10 ppm
  • On-line monitoring instrument
  • Digital hours counter with audible and visual maintenance indicator
  • Economy mode option: Compressor shutdown when nitrogen supply is not required
Model Specifications
No Model Capacity (Nm3/h) Purity Power (KW) Overall size (mm)
1 PN-3-39 3 99.9% 0.5 1800*1400*1500
2 PN-5-29 5 99.5% 0.5 1800*1400*1500
37 PN-80-49 80 99.99% 0.5

Note: For more information, please contact Since Gas System Co., Ltd or send us an email directly.

Applications
  • Metal processing and laser cutting
  • Pharmaceuticals
  • Electronics
  • Food and beverage processing and storage
